Ambient air curtain - ELiS B-N-100 | Flowair

Select the product model:

Ambient air curtain, recess mounting, max. mounting height 5 m, protection class IP21, can be connected to BMS, air flow: three speeds 2300/2700/3500 m³/h, fan power 420 W, length 1 m, height 297 mm, 2 year WARRANTY
Interested in this product? Contact us:

Arvydas Palivonas

LT, RU, EN
+370 601 74426

Sales representative for Vilnius, Ukmergė, Utena, Kaišiadorys and Varėna regions Get Offer

Andrius Lekarevičius

LT, RU, EN
+370 606 11865

Sales representative for Kaunas, Panevėžys, Šiauliai, Telšiai, Klaipėda, Tauragė, Marijampolė and Alytus districts Get Offer
Click on the Model for technical data, dimensions, accessories
ELiS B-N - recess mounting, max. mounting height 5 m, protection class IP21, can be connected to BMS
ELiS B-N-100 Air flow: three speeds 2300/2700/3500 m³/h, fan power 420 W, length 1 m, height 297 mm, 2 year WARRANTY
ELiS B-N-100
Air flow: three speeds 2300/2700/3500 m³/h, fan power 420 W, length 1 m, height 297 mm, 2 year WARRANTY
ELiS B-N-150 Air flow: three speeds 3200/4000/4800 m³/h, fan power 440 W, length 1.5 m, height 297 mm, 2 year WARRANTY
ELiS B-N-150
Air flow: three speeds 3200/4000/4800 m³/h, fan power 440 W, length 1.5 m, height 297 mm, 2 year WARRANTY
ELiS B-N-200 Air flow: three speeds 3600/4300/6600 m³/h, fan power 490 W, length 2 m, height 297 mm, 2 year WARRANTY
ELiS B-N-200
Air flow: three speeds 3600/4300/6600 m³/h, fan power 490 W, length 2 m, height 297 mm, 2 year WARRANTY
Model: ELiS B-N-100
General data
Air flow range (measured verticaly at 2 m/s speed limit)
m
5
Max. air flow
m³/h
3500
Fan data
Power supply
V/Hz
230/50
Max. power consumption
W
420
Max. current consumption
A
1,9
IP / Insulation class
21 / F
Steps
3
Fan data at 3rd (max) speed
Air flow
m³/h
3500
Acoustic pressure level at a distance of 2 m from the unit, in the 500 m³ room of medium capabillity of sound absorption
dB(A)
67
Fan data at 2nd (mid) speed
Air flow
m³/h
2700
Acoustic pressure level at a distance of 2 m from the unit, in the 500 m³ room of medium capabillity of sound absorption
dB(A)
63
Fan data at 1st (min) speed
Air flow
m³/h
2300
Acoustic pressure level at a distance of 2 m from the unit, in the 500 m³ room of medium capabillity of sound absorption
dB(A)
59
Installation data
Installation
Recessed
Other data
Casing
Aluminium, plastic, steel, EPP
Color
White (RAL 9016)
Dimensions
Length
mm
1057
Width
mm
600
Height
mm
297
Weight
kg
31,7

Dimensions

Model: ELiS B-N-100
Dimensions
ELiS B recessed air curtains
Manuals 2.7 MB
Declarations of conformity 659 KB
Brochures 12.9 MB
Catalogue 1.3 MB
AutoCAD drawings 1.1 MB
BIM objects 5.2 MB
