Two steps heating power gas fired heater for direct horizontal blowing - NEXT-R | Robur

Interested in this product? Contact us:

Arvydas Palivonas

LT, RU, EN
+370 601 74426

Sales representative for Vilnius, Ukmergė, Utena, Kaišiadorys and Varėna regions Get Offer

Andrius Lekarevičius

LT, RU, EN
+370 606 11865

Sales representative for Kaunas, Panevėžys, Šiauliai, Telšiai, Klaipėda, Tauragė, Marijampolė and Alytus districts Get Offer
Click on the Model for technical data, dimensions, accessories
NEXT-R series - with axial fan for direct horizontal blowing, pre-mix burner
NEXT R15 9.7 / 14.1 kW two steps heat output, air flow 2000 m³/h, air throw 13 m, electrical power absorption 0.18 kW, max. gas (G20) consumption 1.64 m³/h, weight 26 kg, 2 year WARRANTY
NEXT R15
9.7 / 14.1 kW two steps heat output, air flow 2000 m³/h, air throw 13 m, electrical power absorption 0.18 kW, max. gas (G20) consumption 1.64 m³/h, weight 26 kg, 2 year WARRANTY
NEXT R20 12.5 / 18.7 kW two steps heat output, air flow 2050 m³/h, air throw 15 m, electrical power absorption 0.21 kW, max. gas (G20) consumption 2.17 m³/h, weight 28 kg, 2 year WARRANTY
NEXT R20
12.5 / 18.7 kW two steps heat output, air flow 2050 m³/h, air throw 15 m, electrical power absorption 0.21 kW, max. gas (G20) consumption 2.17 m³/h, weight 28 kg, 2 year WARRANTY
NEXT R30 15.8 / 25.5 kW two steps heat output, air flow 2460 m³/h, air throw 18 m, electrical power absorption 0.21 kW, max. gas (G20) consumption 2.96 m³/h, weight 51 kg, 2 year WARRANTY
NEXT R30
15.8 / 25.5 kW two steps heat output, air flow 2460 m³/h, air throw 18 m, electrical power absorption 0.21 kW, max. gas (G20) consumption 2.96 m³/h, weight 51 kg, 2 year WARRANTY
NEXT R40 21.6 / 35.0 kW two steps heat output, air flow 3600 m³/h, air throw 20 m, electrical power absorption 0.3 kW, max. gas (G20) consumption 4.05 m³/h, weight 56 kg, 2 year WARRANTY
NEXT R40
21.6 / 35.0 kW two steps heat output, air flow 3600 m³/h, air throw 20 m, electrical power absorption 0.3 kW, max. gas (G20) consumption 4.05 m³/h, weight 56 kg, 2 year WARRANTY
NEXT R50 29.1 / 44.6 kW two steps heat output, air flow 3960 m³/h, air throw 25 m, electrical power absorption 0.34 kW, max. gas (G20) consumption 5.18 m³/h, weight 64 kg, 2 year WARRANTY
NEXT R50
29.1 / 44.6 kW two steps heat output, air flow 3960 m³/h, air throw 25 m, electrical power absorption 0.34 kW, max. gas (G20) consumption 5.18 m³/h, weight 64 kg, 2 year WARRANTY
NEXT R60 38.9 / 62.8 kW two steps heat output, air flow 5100 m³/h, air throw 28 m, electrical power absorption 0.5 kW, max. gas (G20) consumption 7.30 m³/h, weight 78 kg, 2 year WARRANTY
NEXT R60
38.9 / 62.8 kW two steps heat output, air flow 5100 m³/h, air throw 28 m, electrical power absorption 0.5 kW, max. gas (G20) consumption 7.30 m³/h, weight 78 kg, 2 year WARRANTY
NEXT R80 47.4 / 76.4 kW two steps heat output, air flow 7200 m³/h, air throw 40 m, electrical power absorption 0.6 kW, max. gas (G20) consumption 8.89 m³/h, weight 91 kg, 2 year WARRANTY
NEXT R80
47.4 / 76.4 kW two steps heat output, air flow 7200 m³/h, air throw 40 m, electrical power absorption 0.6 kW, max. gas (G20) consumption 8.89 m³/h, weight 91 kg, 2 year WARRANTY
NEXT-R two steps heat output gas fired heaters
Manuals 7.5 MB
Declarations of conformity 462 KB
Brochures 1.1 MB
Catalogue 1.6 MB
BIM objects 158.9 MB
OTRG005 thermoregulator
Manuals 3.8 MB
OCDS008 control panel
Manuals 2.8 MB
T-box controller
Manuals 22.7 MB
Declarations of conformity 643 KB
MODBUS protocol for connection to BMS 1.9 MB
DRV R control module for NEXT R gas fired heaters
Manuals 854 KB
