Supercromo series - forced draught system, white colour |
---|
Supercromo 3001 | Supercromo 3002 | |||
Nominal heat input | kW | 2.58 | ||
Heat output | nominal | kW | 2.32 | |
reduced | kW | - | ||
Efficiency | % | 90 | ||
Nominal gas consumption1 | natural gas | m3/h | 0.273 | |
LPG | kg/h | 0.203 | ||
Airflow2 | max | m3/h | 100 | |
min | m3/h | - | ||
Gas pipe diameter | ”F | 3/8" | ||
Air inlet pipe diameter | mm | 49 | ||
Flue pipe diameter | mm | 35 | ||
Wall hole diameter (for concentric pipes) | mm | 50 | ||
Power supply | 230 V 1N - 50 Hz | |||
Wattage | W | 45 | ||
Noise level at 3 m | max. speed | dB(A) | 33 | |
min. speed | dB(A) | - | ||
Dimensions | width | mm | 478 | |
height | mm | 577 | ||
depth | mm | 173 | ||
Weight | kg | 17 |
Gas convectors series quick to install and advantageous in the operation. Each heater is independent and optimizes the comfort of every environment.
Thanks to the small dimensions, Supercromo 3001 is the ideal solution for small premises as well as rooms with a low windowsill. It warms up the room very quickly and keeps the noises low thanks to the centrifugal fan.
Supercromo 3002 combines the features of 3001 model with more operating possibilities like the humidifier and the programmable timer (150h charging system), supplied as standard. Heating where you need it and when you need it, with small sizes and low consumptions.
Supercromo 8002 is the ideal solution for workshops, bars, show-rooms, restaurants, shops. It is equipped with humidifier, programmable timer (150h charging system), double heating power, thanks to the two-steps burner and fan, summer ventilation and air filter.
Supercromo 3001 | Supercromo 3002 | |
Two power settings | - | - |
Centrifugal fan | + | + |
Room thermostat | + | + |
Summer ventilation | - | - |
Air filter | - | - |
Humidifier | - | + |
Programmable timer with reserve charge of 150 hours | ? | + |
500 mm concentric pipe | + | + |
External flue terminal | + | + |
LPG kit | + | + |
+ in standard
? ordered separately
- not available
