Gas absorption heat pump - GAHP-GS | Robur

Select the product model:

Gas absorption heat pump, geothermal, takes heat from Ground and gives it to Water for heating or domestic hot water production, maximum outlet water temperature for heating/DHW 65/70°C, heating capacity 41.6 kW (B0/W35), G.U.E. gas utilization efficiency 165% (B0/W35), A++ energy class ErP on 55°C operation, gas (G20) consumption 2.67 m³/h, electrical power consumption 0.41 kW, sound pressure level (at 5 m distance) 44.1 dB(A), water connection 1¼", electrical degree of protection IP X5D, weight 300 kg, outside working temperature -15°C/+45°C, can be ordered with special winter kit for operation on lower temperature down to -30°C
Interested in this product? Contact us:

Arvydas Palivonas

LT, RU, EN
+370 601 74426

Sales representative for Vilnius, Ukmergė, Utena, Kaišiadorys and Varėna regions Get Offer

Andrius Lekarevičius

LT, RU, EN
+370 606 11865

Sales representative for Kaunas, Panevėžys, Šiauliai, Telšiai, Klaipėda, Tauragė, Marijampolė and Alytus districts Get Offer
Click on the Model for technical data, dimensions, accessories
GAHP-GS - geothermal, takes heat from Ground and gives it to Water for heating or domestic hot water production
GAHP-GS Maximum outlet water temperature for heating/DHW 65/70°C, heating capacity 41.6 kW (B0/W35), G.U.E. gas utilization efficiency 165% (B0/W35), A++ energy class ErP on 55°C operation, gas (G20) consumption 2.67 m³/h, electrical power consumption 0.41 kW, sound pressure level (at 5 m distance) 44.1 dB(A), water connection 1¼", electrical degree of protection IP X5D, weight 300 kg, outside working temperature -15°C/+45°C, can be ordered with special winter kit for operation on lower temperature down to -30°C
GAHP-GS
Maximum outlet water temperature for heating/DHW 65/70°C, heating capacity 41.6 kW (B0/W35), G.U.E. gas utilization efficiency 165% (B0/W35), A++ energy class ErP on 55°C operation, gas (G20) consumption 2.67 m³/h, electrical power consumption 0.41 kW, sound pressure level (at 5 m distance) 44.1 dB(A), water connection 1¼", electrical degree of protection IP X5D, weight 300 kg, outside working temperature -15°C/+45°C, can be ordered with special winter kit for operation on lower temperature down to -30°C
Model: GAHP-GS
Heating operation mode data
Energy class (55°C operation)
ErP
A++
G.U.E. gas utilization efficiency at 35°C water and 0°C ground temperature
%
165
Heating capacity at 35°C water and 0°C ground temperature
kW
41,6
Heating capacity recovered from renewable source at 35°C water and 0°C ground temperature
kW
16,4
G.U.E. gas utilization efficiency at 50°C water and 0°C ground temperature
%
149
Heating capacity at 50°C water and 0°C ground temperature
kW
37,6
Heating capacity recovered from renewable source at 50°C water and 0°C ground temperature
kW
12,1
Nominal water flow rate (ΔT = 10°C)
m³/h
3,17
Nominal water pressure loss (outlet water at 50°C)
kPa
49
Maximum outlet water temperature (heating / DHW)
°C
65 / 70
Maximum inlet water temperature (heating / DHW)
°C
55 / 60
Operating temperature range
°C
-15 / +45
Operating temperature range with winter kit
°C
-30 / +45
Burner characteristics
Thermal input (actual)
kW
25,2
Natural gas (G20) consumption at 15 °C - 1013 mbar
m³/h
2,67
LPG G30 / G31 consumption at 15 °C - 1013 mbar
kg/h
1,99 / 1,96
Installation data
Power supply
V/Hz
230/50
Nominal electrical power consumption
kW
0,41
Sound pressure at 5 meters distance from unit front side in free field
dB(A)
44,1
IP protection class
X5D
Hydraulic connection
Ø "
F 1 1/4
Gas connection
Ø "
F 3/4
Exhaust air flue diameter
mm Ø
80
Dimensions
Width
mm
848
Depth
mm
690
Height
mm
1278
Weight
kg
300

Dimensions

Model: GAHP-GS
Dimensions

Gas powered absorption heat pump GAHP-GS is designed for high efficiency heating and domestic hot water production in geothermal applications.

Advantages

  • Up to 39.4% utilisation of ground-source renewable energy. Designed to exceed peak efficiency (G.U.E. - Gas Utilization Efficiency) of 165%
  • Reduction in investment costs for geothermal loops can be higher than 50% in comparison to electric heat pumps.
  • It is a super-efficient solution for domestic hot water production.
  • It provides up to 40% of running cost savings if compared with the best condensing boilers.
  • It represents the most profitable investment to increase the value of the building and its energy performance rating.
  • It reduces electricity requirements compared to traditional electrical systems, thanks to the prevalent use of natural gas.
  • It is eligible for national and local incentive programs all over Europe.
  • With a GAHP-GS, every year 4.6 Tons of CO2 emissions are saved, which are equivalent to those absorbed by 656 trees or those produced by 2 green cars; every year 2.2 Tons of Oil Equivalent are saved. Moreover, Robur GAHP-GS uses natural refrigerants not subject to normal constraints and phase-out (F-Gas Regulation exempt).

Applications

  • Ideal for heating and DHW in buildings with high natural gas/LPG consumption.
  • Ability to supply cooling as free-cooling mode (unit off) or in geothermal applications with active cooling (unit on).
  • For indoor and outdoor installation.

Versions

  • Available also in:
    • pre-assembled units for higher capacity.
GAHP-GS geothermal gas absorption heat pump Ground/Water
